- Place of Origin: anhui
- Brand Name: laifu
- Model Number: MB8 Series ( Full CNC )
Control System:
Delem from Netherland: DA52s, DA56, DA65w, DA66T, DA69w
Esa from Italy: KV S525, KV S540
Cybelec from Swithzerland: DNC600, DNC880S
Type | 63T/2500 | 80T/3200 | 100T/3200 | 160T/3200 | 200T/3200 |
Nominal Force (KN) | 630 | 800 | 1000 | 1600 | 2000 |
Bending Length (mm) | 2500 | 3200 | 3200 | 3200 | 3200 |
Distance Between Holes (mm) | 1900 | 2700 | 2700 | 2700 | 2700 |
Depth of Throat (mm) | 350 | 350 | 400 | 400 | 400 |
Slider Travel (mm) | 170 | 170 | 200 | 200 | 200 |
Height Worktable (mm) | 800 | 800 | 800 | 800 | 800 |
Height of Die Loading (mm) | 380 | 380 | 420 | 420 | 420 |
Main Power (Kw) | 5.5 | 7.5 | 7.5 | 11 | 15 |
Compensation Cylinder Number | 2 | 3 | 3 | 3 | 3 |
Control Axes | 3 1 | 3 1 | 3 1 | 3 1 | 3 1 |
Rear Stopper x Axis Travel(mm) | 500 | 500 | 500 | 500 | 500 |
Rear Stopper x Axis Speed (mm/s) | 200 | 200 | 200 | 200 | 200 |
Overal Dimension(LxWxH)(mm) | 3100x1450x2050 | 3500x1550x2100 | 3500x1580x2400 | 3500x1650x2500 | 3500x1680x2550 |
Weight(T) | 5.8 | 7.8 | 8.5 | 11 | 14.2 |
Type | 250T/3200 | 320T/3200 | 400T4000 | 500T/5000 | 500T/6000 |
Nominal Force (KN) | 2500 | 3200 | 4000 | 5000 | 5000 |
Bending Length (mm) | 3200 | 3200 | 4000 | 5000 | 6000 |
Distance Between Holes (mm) | 2700 | 2700 | 3500 | 3900 | 4900 |
Depth of Throat (mm) | 400 | 400 | 400 | 500 | 500 |
Slider Travel (mm) | 200 | 200 | 200 | 320 | 320 |
Height Worktable (mm) | 800 | 800 | 800 | 800 | 800 |
Height of Die Loading (mm) | 420 | 420 | 420 | 600 | 600 |
Main Power (Kw) | 15 | 18.5 | 22.5 | 37 | 37 |
Compensation Cylinder Number | 3 | 3 | 4 | 5 | 6 |
Control Axes | 3 1 | 3 1 | 3 1 | 3 1 | 3 1 |
Rear Stopper x Axis Travel(mm) | 500 | 500 | 500 | 500 | 500 |
Rear Stopper x Axis Speed (mm/s) | 200 | 200 | 200 | 200 | 200 |
Overal Dimension(LxWxH)(mm) | 3500x1700x2600 | 3500x1800x2730 | 4300x2080x2730 | 5400x2525x4600 | 6500x2525x4200 |
Weight(T) | 15.6 | 16.8 | 31 | 38 | 53 |
| Type
| 500T/7000
| 600T/5000
| 600T/6000
| 600T/7000
|
| Nominal Force (KN)
| 5000
| 6000
| 6000
| 6000
|
| Bending Length (mm)
| 7000
| 5000
| 6000
| 7000
|
| Distance Between Holes (mm)
| 4900
| 3900
| 4900
| 5900
|
| Depth of Throat (mm)
| 500
| 500
| 500
| 500
|
| Slider Travel (mm)
| 320
| 320
| 320
| 320
|
| Height Worktable (mm)
| 800
| 800
| 800
| 800
|
| Height of Die Loading (mm)
| 600
| 600
| 600
| 600
|
| Main Power (Kw)
| 37
| 45
| 45
| 45
|
| Compensation Cylinder Number
| 6
| 5
| 6
| 7
|
| Control Axes
| 3 1
| 3 1
| 3 1
| 3 1
|
| Rear Stopper x Axis Travel(mm)
| 500
| 500
| 500
| 500
|
| Rear Stopper x Axis Speed (mm/s)
| 200
| 200
| 200
| 200
|
| Overal Dimension(LxWxH)(mm)
| 7500x2525x4900
| 5500x2450x4500
| 6500x2450x5100
| 7500x2450x5200
|
| Weight(T)
| 60
| 65
| 68
| 72
|
